S6-GC(25-60)K-US
Solis Three Phase Grid-Tied Inverters
Detail
Efficient:
Max. efficiency 98.8% (CEC efficiency 98.5%)
String current up to 20A
3/4 MPPT design, supports multiple orientation system design
Night time PID recovery function, increases overall system yield (optional)
Wide voltage range and low startup voltage
Safe:
Type 4X, C5 Anti-Corrosion Level
AFCI protection, proactively reduces fire risk
Intelligent redundant fan-cooling
Integrated module level rapid shutdown transmitter
High quality components from globally recognized suppliers
Integrated DC and AC disconnects
Smart:
Equipped with external power control interface, supporting zero output power control
Intelligent string monitoring, smart I-V curve scan
Supports RS485, Ethernet, WiFi, Cellular
Scan to register on SolisCloud, supports remote upgrade and control
Economic:
> 1.5 DC/AC ratio
Supports high power modules for lower installation costs
Separable AC wiring box
Models:
S6-GC25K-US / S6-GC33K-US
S6-GC36K-US / S6-GC40K-US
S6-GC50K-US / S6-GC60K-US
Ordering: S6-GC(25-60)K-US
APST (APS MLRSD Transmitter)
RSS (Tigo MLRSD Transmitter)
NEPT (NEP MLRSD Transmitter)
DATASHEET
| Models | 25K | 33K | 36K | 40K | 50K | 60K |
| Input DC | ||||||
| Max. input voltage | 1000 V | |||||
| Rated voltage | 720 V | |||||
| Start-up voltage | 180 V | |||||
| MPPT voltage range | 180-1000 V | |||||
| Max. input current | 3*40 A | 4*40 A | ||||
| Max. short circuit current | 3*63 A | 4*63 A | ||||
| MPPT number/Max. input strings number | 3/6 | 4/8 | ||||
| Output AC | ||||||
| Rated output power | 25 kW | 33 kW | 36 kW | 40 kW | 50 kW | 60 kW |
| Max. apparent output power | 27.5 kVA | 36.3 kVA | 39.6 kVA | 44 kVA | 55 kVA | 66 kVA |
| Max. output power | 27.5 kW | 36.3 kW | 39.6 kW | 44 kW | 55 kW | 66 kW |
| Rated grid voltage | 3Ф/PE, 480 V | |||||
| Rated grid frequency | 60 Hz | |||||
| Max. output current | 33.1 A | 43.7 A | 47.6 A | 52.9 A | 66.2 A | 79.4 A |
| Power factor | >0.99 (0.8 leading - 0.8 lagging) | |||||
| THDi | <3% | |||||
| Efficiency | ||||||
| Max. efficiency | 98.8% | |||||
| CEC efficiency | 98.5% | |||||
| Protection | ||||||
| DC reverse-polarity protection | Yes | |||||
| Short circuit protection | Yes | |||||
| Output over current protection | Yes | |||||
| Surge protection | DC Type II / AC Type II | |||||
| Grid monitoring | Yes | |||||
| Anti-islanding protection | Yes | |||||
| Temperature protection | Yes | |||||
| Strings monitoring | Yes | |||||
| I/V Curve scanning | Yes | |||||
| Integrated AFCI (DC arc-fault circuit protection) | Yes | |||||
| Integrated PID recovery | Optional | |||||
| Integrated DC switch | Yes | |||||
| Integrated AC switch | Yes | |||||
| General Data | ||||||
| Dimensions (W*H*D) | 30.9*21.6*12.6 in (784*549*320 mm) | |||||
| Weight | 96.3 lbs (43.7 kgs) | 105.4 lbs (47.8 kgs) | 108.7 lbs (49.3 kgs) | 110.5 lbs (50.1 kgs) | ||
| Topology | Transformerless | |||||
| Self-consumption (night) | <1 W | |||||
| Relative humidity | 0-100% | |||||
| Operating ambient temperature range | -13°F to 140°F (-25°C to 60°C) | |||||
| Ingress protection | TYPE 4X | |||||
| Cooling concept | Natural convection | |||||
| Max. operation altitude | 13,120 ft (4000 m) | |||||
| Compliance | UL1741SB, UL1741SA, IEEE 1547-2018, UL1699B, UL1998, FCC Part15 ClassB, California Rule 21, Heco Rule 14H, NEC 690.12-2020, CAN/CSA C22.2107.1-1 | |||||
| Features | ||||||
| DC connection | MC4 connector | |||||
| AC connection | OT terminal (4 AWG to 3/0 AWG) | |||||
| Display | LCD | |||||
| Communication | Modbus RTU (Sunspec compliant), RS485, Optional: Cellular, Wi-Fi | |||||
